StoneL Eclipse EN97 AS-i Extended Addressing VCT EN97C02RA EN97D02RA EN97C05RA EN97D05RA

StoneL EN97C02RA is a requested ordering reference in the StoneL Eclipse EN97 AS-Interface Extended Addressing Valve Communication Terminal family. This variable product covers EN97C02RA, EN97D02RA, EN97C05RA and EN97D05RA. The EN97 family is designed for compatible AS-i industrial valve communication systems where extended network addressing is required.

StoneL Eclipse valve communication terminals combine field-level communication with valve position monitoring functions in a compact product platform. For replacement and procurement projects, customers should verify the complete model number, network compatibility and installation arrangement before placing an order.

StoneL EN97C02RA Eclipse AS-i Extended Addressing VCT

Industrial process facilities often operate numerous automated valves across production areas. Each valve may need to communicate its operating status to a controller, while the automation system may also need to command compatible solenoid equipment. Field communication networks help organize these connections.

AS-Interface, also known as AS-i, is an industrial communication protocol used with compatible sensors and actuators. The StoneL Eclipse EN97 belongs to the AS-i extended-addressing family, which differs from the standard-addressing EN96 configuration.

Extended addressing supports additional device addresses on a compatible AS-i network. Manufacturer literature identifies support for up to 62 devices per network in the applicable extended-addressing architecture. Actual capacity depends on the network master, device addressing mode and other system requirements.

The Eclipse EN97 family includes valve-related input and output functions. However, exact wiring, power limits, connection details and supported configurations must be confirmed against the appropriate manufacturer installation instructions. The four supplied ordering references should not be assumed to have identical mechanical connections.

Available StoneL Eclipse EN97 Models

This WooCommerce variable product contains four ordering references. Each reference should be configured as a separate variation with its own SKU. The table preserves the complete supplied model numbers without assigning unverified connector dimensions or certification details.

Model Verification Notice: The complete suffixes must be checked against the original product nameplate or manufacturer ordering records. Listing these models together does not establish that they are directly interchangeable.

Technical Overview of the Eclipse EN97 Family

The following table summarizes published characteristics of the StoneL AS-Interface extended-addressing VCT family. These are family-level references rather than individually verified specifications for every supplied ordering code.

For electrical ratings, output loading, wiring diagrams and environmental approvals, consult the installation instructions for the actual device. A model-family description should never replace engineering verification of the complete ordered product.

Key Features and Functions

AS-i Extended Addressing

The EN97 family supports extended addressing on compatible AS-Interface networks. This distinguishes it from the EN96 standard-addressing family. Extended addressing can be useful in installations with larger numbers of suitable field devices, subject to network design constraints.

Valve Position Feedback

Manufacturer literature describes discrete position sensor inputs in the VCT platform. These allow compatible valve status information to be communicated through the network. The actual interpretation of open and closed signals depends on the installed actuator and control system.

Auxiliary Field Inputs

Published EN97 family information identifies auxiliary discrete input capability. This may be relevant where additional compatible field signals are needed. Wiring and electrical compatibility must be checked against the device-specific instructions.

Solenoid Control Outputs

The VCT family includes power outputs intended for compatible solenoid applications. Before connecting a solenoid, the engineer must verify the output electrical rating, wiring requirements and intended control function. No universal solenoid compatibility should be assumed.

Compact Eclipse Construction

The StoneL Eclipse platform combines monitoring and communication functions in a compact industrial enclosure arrangement. It is associated with suitable automated valve actuators. The required mounting hardware and physical clearances must be verified for each installation.

Industrial Applications

StoneL Eclipse EN97 valve communication terminals may be relevant to compatible AS-i automated valve systems in oil and gas, petrochemical processing, chemical manufacturing, power generation, water treatment, pulp and paper, and industrial utility facilities.

In these industries, networked valve equipment can help integrate field status information into the plant automation architecture. This may support operating sequence monitoring, equipment supervision and maintenance activities.

Application suitability depends on the installed AS-i network, actuator mounting arrangement, field wiring and environmental conditions. For hazardous locations, the exact unit’s certification and installation requirements must be verified from the manufacturer documentation and product markings.

StoneL EN97 Model Selection Guide

Step 1: Confirm the network protocol. Verify that the existing system uses AS-Interface and supports the extended-addressing mode required by the EN97 family.

Step 2: Check the complete model number. Identify whether the original device is EN97C02RA, EN97D02RA, EN97C05RA or EN97D05RA. Record the full code exactly as shown on the nameplate.

Step 3: Review the AS-i master. Confirm addressing compatibility, network configuration and any limitations associated with the installed controller. Do not assume that every AS-i master supports every extended-addressing configuration.

Step 4: Verify field connections. Compare the original wiring, cable connections and any solenoid requirements with the proposed replacement.

Step 5: Confirm mechanical compatibility. Review actuator mounting hardware, available installation space and the physical configuration of the device.

Step 6: Check the installation environment. Verify environmental ratings and any required hazardous-area approvals for the exact product configuration.

Step 7: Request commercial confirmation. Provide the complete model number, required quantity, shipping destination and preferred delivery schedule when requesting a quotation.

Why Choose Wuhan Yuli Automation?

Wuhan Yuli Automation Technology Co., Ltd. supplies industrial automation components for customers in international markets. Our portfolio includes StoneL valve monitors, valve communication terminals, intelligent valve positioners, industrial controllers, communication modules and power supplies.

We focus on new and original products and provide a minimum one-year warranty under our standard sales commitment. Our team can assist with product identification, sourcing inquiries, quotation preparation and international order coordination.

Browse Wuhan Yuli Automation’s industrial automation website for related process control equipment and purchasing information.

For official manufacturer information, visit the Valmet StoneL product overview and review the StoneL technical guide.

Frequently Asked Questions

What is StoneL EN97C02RA?

StoneL EN97C02RA is a supplied ordering reference associated with the Eclipse EN97 AS-i Extended Addressing Valve Communication Terminal family. The complete configuration should be confirmed before purchase.

What is the difference between EN96 and EN97?

EN96 is the standard-addressing AS-i family, while EN97 supports extended addressing. The correct selection depends on the installed network and device requirements.

Can EN97 support 62 devices on one network?

Manufacturer literature describes up to 62 devices in compatible extended-addressing AS-i configurations. Actual supported capacity depends on the network master, device types and system design.

Are EN97C02RA and EN97D02RA interchangeable?

Direct interchangeability has not been confirmed. The complete ordering codes, connections, installation arrangements and applicable approvals should be reviewed.

What is the difference between EN97C05RA and EN97D05RA?

These are distinct ordering references. Their precise configuration differences must be verified using manufacturer documentation or original equipment records.

How can I request a StoneL EN97 quotation?

Contact Wuhan Yuli Automation with the exact model number, quantity and shipping destination. A clear photograph of the existing product nameplate can help verify replacement requirements.
