The ABB NTMF01 Termination Unit, also known as the ABB Bailey NTMF01 Multi-Function Controller Termination Unit, is a termination assembly for the INFI 90 industrial process control system. According to product instruction I-E96-427B, the unit provides termination connections for compatible controller and communication modules, including two RS-232-C ports and a serial link associated with an NTCS04 Control I/O Termination Unit.
Wuhan Yuli Automation Technology Co., Ltd. supports international customers sourcing ABB Bailey industrial automation spare parts. Contact our team to request NTMF01 product identification, supply availability, lead time and a formal quotation for your maintenance or replacement project.
ABB NTMF01 Termination Unit Overview
Industrial process control systems require dependable connections between electronic modules, control equipment and external devices. Termination units provide defined connection points within the original system architecture. Selecting the correct assembly is important when maintaining an existing automation installation.
The NTMF01 is identified in Bailey INFI 90 documentation as a Multi-Function Controller Termination Unit. The product instruction describes its use with a multi-function controller and several communication transfer module types.
These include an INFI-NET to computer transfer module, a Plant Loop to Plant Loop transfer module and a Plant Loop to computer transfer module. The appropriate arrangement depends on the installed equipment and its documented configuration.
The NTMF01 provides termination for two separate RS-232-C ports. The manual also describes a serial link used to connect a control station through an NTCS04 Control I/O Termination Unit.
These functions distinguish NTMF01 from general-purpose terminal boards. However, buyers must still verify the complete part number, installed modules, connection requirements and hardware condition before purchasing a replacement.
For accurate spare parts identification, customers should provide photographs of the original unit, any additional assembly markings and information about the associated control system.
ABB NTMF01 Technical Information
| Item | Information |
|---|---|
| Brand / Product Family | ABB Bailey / INFI 90 |
| Model | NTMF01 |
| Product Type | Multi-Function Controller Termination Unit |
| System Family | INFI 90 |
| Documented Serial Interfaces | Two separate RS-232-C ports |
| Related Termination Unit | NTCS04 Control I/O Termination Unit |
| Technical Reference | Product Instruction I-E96-427B |
| Availability | Subject to supplier confirmation |
Technical note: The information above is based on the NTMF01 product instruction. Electrical ratings, dimensions, individual connector assignments and approved replacement alternatives should be checked against the full applicable documentation rather than assumed.
NTMF01 Functions and Product Features
Multi-Function Controller Termination
The NTMF01 provides termination connections associated with a multi-function controller in the INFI 90 system. This documented function is important when identifying the correct termination assembly for an installed controller arrangement.
Before ordering, maintenance engineers should compare the existing unit with the required model and confirm that the associated controller configuration matches the equipment documentation.
Two RS-232-C Ports
The product instruction identifies two separate RS-232-C termination ports. This is a documented interface feature rather than an assumption based on the product name.
Actual cable connections, signal assignments and configuration requirements must follow the original equipment documentation. Buyers should verify the required connection arrangement when requesting replacement hardware.
Serial Link Through NTCS04
The NTMF01 documentation describes a serial link connecting a control station through an NTCS04 Control I/O Termination Unit. This relationship is useful for customers identifying associated components within the same installation.
NTMF01 and NTCS04 perform different documented roles. Their relationship does not mean that one unit can replace the other.
Communication Transfer Module Termination
Manufacturer documentation also describes NTMF01 termination applications involving INFI-NET to computer, Plant Loop to Plant Loop and Plant Loop to computer transfer modules.
These functions depend on the original system architecture. Buyers should provide the associated module reference to help clarify the intended purchasing requirement.
Model-Specific Spare Parts Identification
Using the exact NTMF01 model number helps purchasing teams distinguish this assembly from other ABB Bailey termination units. Any additional hardware revision or assembly identification should be recorded when available.
Industrial Applications and Maintenance Environments
ABB Bailey INFI 90 equipment is associated with industrial process control installations. Facilities maintaining compatible legacy automation systems may require replacement termination hardware for scheduled maintenance or spare parts inventory.
Industrial sectors that commonly use process automation include power generation, chemical processing, oil and gas, pulp and paper, water treatment and manufacturing.
These sectors are general examples of process control environments. They do not establish that NTMF01 is approved for every application within those industries.
For an existing installation, maintenance teams should identify the original control equipment, connected communication modules and associated termination assemblies. The system documentation should guide replacement selection and installation planning.
When preparing a spare parts request, it is useful to record the complete model number, quantity, destination country and any required revision information.
ABB NTMF01 Selection and Purchasing Guide
Step 1: Verify the Original Model
Confirm that the installed termination unit is marked NTMF01. Record any additional assembly identifiers, label information or revision markings that may affect replacement selection.
Step 2: Identify the Associated Modules
Determine whether the installation involves a multi-function controller or one of the documented transfer module arrangements. Provide this information when requesting a quotation.
Step 3: Review Connection Requirements
Consult the applicable NTMF01 product instruction and original wiring documentation. Confirm the required RS-232-C connections, associated control station arrangement and relevant termination hardware.
Step 4: Confirm Product Condition
Specify whether new original equipment is required. Request confirmation of the offered model, product condition, supplied accessories, packaging and warranty terms.
Step 5: Request a Formal Quotation
Send the model number NTMF01, required quantity, shipping destination and preferred delivery schedule. Confirm price, actual availability, lead time and supply scope before placing an order.
Why Choose Wuhan Yuli Automation?
Wuhan Yuli Automation Technology Co., Ltd. is an industrial automation trading company established in 2017. We assist international customers with sourcing inquiries for industrial control equipment and spare parts.
Our product range includes ABB controllers, communication modules, I/O equipment, power supplies, termination units and other industrial components. Customers can submit model-specific inquiries for maintenance or replacement purchasing.
Our standard offering focuses on new, original products with at least a one-year warranty, subject to confirmation in the formal quotation. Actual availability, product condition and delivery terms must be confirmed for the exact item offered.
For related ABB Bailey termination hardware, see our ABB MFT01 and MFT02 Termination Units. This related product link is provided for navigation and does not imply interchangeability with NTMF01.
For manufacturer information, visit the official ABB website. For model-specific reference, consult the NTMF01 Product Instruction I-E96-427B.
Frequently Asked Questions
What is the ABB NTMF01 Termination Unit?
NTMF01 is a Bailey INFI 90 Multi-Function Controller Termination Unit. Its product instruction describes termination connections for compatible controllers and communication transfer modules.
How many RS-232-C ports does NTMF01 provide?
The product instruction identifies two separate RS-232-C termination ports. The applicable connection details should be reviewed in the full technical documentation.
What is the relationship between NTMF01 and NTCS04?
The manual describes a serial link connecting a control station through an NTCS04 Control I/O Termination Unit. The two models have different functions and should not be treated as interchangeable.
Is NTMF01 used with INFI 90 equipment?
Yes. The NTMF01 product instruction identifies it as termination hardware for the INFI 90 system family. Exact installation compatibility must still be confirmed.
Can another termination unit replace NTMF01?
No replacement equivalence is established here. Any proposed alternative requires appropriate manufacturer documentation and technical confirmation.
Can I request a new original NTMF01?
Customers can submit an inquiry for new original equipment. Actual availability, condition and delivery time are subject to quotation confirmation.
What information is needed for a quotation?
Provide the NTMF01 model number, required quantity, destination country and original product identification. Include associated module information when available.
Request a Quote – ABB NTMF01
ABB Bailey NTMF01 Multi-Function Controller Termination Unit
Looking for NTMF01 for an ABB Bailey INFI 90 installation? Contact Wuhan Yuli Automation for product identification, supply availability, delivery information and a formal quotation.
Please include: Model NTMF01, quantity, original component label, associated equipment and shipping destination.
Email: sales@wuhanyuli.com
